Lama Metal Door and Window Frames provide a secure fix for timber and metal doors where strength and durability factors are your priorities. Due to the deplenishing sources of wood used in the door and window frame industry, coupled with the rise in expense including the world’s rapidly disappearing timber resources, Lama Metal Door and Window frames are the best alternatives you can turn to, and at the same time, helping us to preserve our future generations by avoiding green house and environmental effects caused by deforestation.

Lama Metal Door and Window frames are used extensively and are preferred to timber frames due to its cost effectiveness and real practical advantages over timber frames. Our metal frames are easily fitted during construction or can be retrofitted, complete with hinges, architraves, buffers and striker plates already built in. They are much easier to fit once familiarized, stronger, more resilient and provides an excellent painting surface as no surface preparation is required. Due to the utilization of specially coated metals, termites attack to your door frame and warpage of timber door frames especially when exposed to moisture is an issue of the past. Once fitted, the metal door or window frame becomes an integral part of the wall which adds to its strength. Lama Metal Door and Window Frames are available in both rolled and pressed formed with various profiles and material type to suit your taste and budget.

Lama Metal Door and Window Frames are made out of superb high quality materials utilizing the latest roll and press forming technology. Our highly skilled staffs, have been trained to produce export quality controlled metal door and window frames under our stringent quality control measures.

Lama Metal Door Frames have many benefits. These includes:

    • Cost Efficiency
    • Extra Strength and Durability
    • Environmentally Friendly
    • Stronger and Safer in the Long Run
    • High Quality and Design
    • Convenient and Lightweight
    • Quicker and Easier Installation
    • Efficient After Sales Service and Friendly Staffs
    • High Level of Aesthetics
    • Price Competitiveness
    • Flexibility in Production Specifications Made To Your Requirements
    • IKRAM Approved

..................................................................

Metal Door Frame

Shock Absorbing Buffers
Buffers are incorporated into Lama deluxe door frames reducing noise and vibration

Unique Striker Plate
A unique stainless steel screwed-in striker plate with a gently curve lead-in edge. It is less obstructive, looks better and does not interfere with the clean lines of the frame. An adjustable tongue is included.

Built-in Architrave
A neatly curved built-in architrave enhances the appearance of the Lama deluxe door frame, ensures a precise fit, avoids extra filling and the subsequent risk of plaster cracking.



Precision-Cut Corner Junctions
Absolute precision is our trade mark. Each corner has been pre-cut with a 45° mitre giving a snug, accurate fit. Quick and easy to fix leaving superb finish.



Unobstructive Hinges
Neat, slimline, loose-pin zinc coated hinges are built-in to all Lama deluxe door frames. Made to fit quickly and easily without detracting from the overall design.

Back Openings
Supplied in a choice of sizes. 95mm for modular brickwork and 114 mm to suit standard bricks.

Temporary Spreader Bar
Lama deluxe frames are supplied with temporary bottom rails to ensure a perfect square during transportation and installation. They are designed to be easily removed.

Lama Metal Door Frames comes in a package of the essential hardware accessories which includes the following:

• Three sets on Lama loose pin slotted chromate steel hinges (2.0mm Thickness). Lama Stainless Steel Hinges can be provided upon specification at an additional cost. All Lama hinges are slimline and unobstructive.
• A Stainless Steel Striker Plate for a hard wearing long lasting operation and convenience. Its screwed in design with a gentle curve lead-in edge is less obstructive, does not interfere with the clean lines of the door frame and has a high level of aesthetics.
• Two Rubber Buffer for the closing jamb to reduce impact, noise and vibrations upon closing the door.
• Welded Mortar Guards for Screw on Hinges (if specified) for the protection of the screw threads to provide a long lasting serviceability. Mullions are slotted on the door frame to conceal the hinge back plate.
• Each Door Frame is supplied with a Spreader Bar to ensure squareness during transportation and installation.
• Each Door Frame is supplied with identification for Right or Left Hand Opening.
• A Quantity of 8 Steel Brick Ties or 6 pieces of Door Frame Mounting Brackets are supplied with each Door Frame to ensure a tight and permanent fix before the curing of the mortar.
• A Complete Sturcture of Door Stop, Architrave are all built in. (Budget Profile Does not Include Architrave)

Lama Metal Door Frames are available in a variety of specially coated steels. Amongst the most popular materials are Zincanneal, Galvanneal, Galvanised Iron and Electro-Galvanneal, in thicknesses of 0.8mm, 1.0mm and 1.2mm, in 5 different profiles:

• Budget Frame Press Formed Profile
• Arch Frame Roll Formed 130mm Profile
• Arch Frame Roll Formed 140mm Profile
• Standard Frame Roll Formed 150mm Profile
• Standard Frame Roll Formed 158mm Profile

All Lama Metal Door Frame dimensions can be made to order, including double leaf doors. Budget profile can be made is various back opening sizes and in any desired profile. Additional charges incurs.


ORDERING PROCEDURE FOR LAMA METAL DOOR FRAMES

Please specify the following on purchase order when ordering:

    • Profile / type of frame
    • Frame overall size / dimensions
    • Frame back opening and block size (for press brake profile)
    • Right or left hand door opening
    • Single or double leaf door (no. of required hinges)
    • With or without striker plate for spring latch, dead bolts or combination of both.
    • Quantity required
    • Full delivery address and contact details

    Goods are considered sold upon receipt of purchase order and
    commencement of job. The customer is liable for any additional
    costs incurred for changes / alterations thereafter.



....................................................................

Metal Window Frame

Louver Window
HEIGHT WIDTH
4' 2'
4' 4'
4' 6'
4' 8'
2' 2'
2' 4'
2' 6'

Door & Window Combination

Casement Window

Lama Metal Window Frames comes in a package of the essential hardware accessories which includes the following options:

• Adjustable louvers either single or double control
• Fixed glass louver holder
• Security Bars (12mm unless Specified)
• Water Stop Bars
• Louvre Holders to hold 4mm thick Glass


Lama Metal Window Frames are available in a variety of specially coated steels. Amongst the most popular materials are Zincanneal, Galvanneal, Galvanised Iron and Electro-Galvanneal, in thicknesses of 0.8mm, 1.0mm and 1.2mm, in 5 different profiles:

• Budget Frame Press Formed Profile
• Arch Frame Roll Formed 130mm Profile
• Arch Frame Roll Formed 140mm Profile
• Standard Frame Roll Formed 150mm Profile
• Standard Frame Roll Formed 158mm Profile

All Lama Metal Window Frame dimensions can be made to order including Casement Window Frame.

Lama Metal Products can also provide you with a Door and Window Joint if required.


Please note that Galvanised Iron requires a layer of Epoxy Primer/Paint to allow paint permeability.


ORDERING PROCEDURE FOR LAMA METAL WINDOW FRAMES

Please specify the following on purchase order when ordering:

    • Profile / Type of Frame
    • Frame Overall Size / Dimensions
    • Frame Back Opening and Block Size (for press brake profile)
      *Right or left hand, inwards or outwards door openings for both door / window combinations and door frame with glass louvred top hung.
    • With or without fixed glass louvre
    • With or without security bars
    • Quantity required
    • Full delivery address and contact details

Goods are considered sold upon receipt of purchase order and
commencement of job. The customer is liable for any additional
costs incurred for changes / alterations thereafter.







    Each frame is supplied with easy to install 4mm steel brick ties. Brick ties supplied to ensure each brick,a tight permanent fit.








    IMPORTANT NOTE:

    Custom Sizes can be manufactured to your requirements / specifications
    if quantities exceed 100 units.

    Lama Metal reserves the rights to alter specifications for product
    development without prior notice.
